Flat Roof Solar Rack
If the flat roof is concrete surface, we recommend using concrete base, eliminating the need for waterproof and damage to the roof structure. The components of solarun Flat Roof Solar Rack is limited, install quickly, and can reduce labor costs.
1.Simple and fast installation.
Only use simple tools to install.Our special stainless steel T bolts can be put into the rail from the any location and can be high pre-assembly with the clamp and hook. No welding and drill in the press of installation, so can minimize the time and cost of installation.
2. High strength.
With all structural components comprised of high class stainless steel 304 and anodized alloy, it is designed for 25 years service life and 10 years warranty.
3.Strong applicability.
Solarun mounting system can suit for any size framed or unframed modules.
Features: Place of use: Flat rooftop
Wind load: max.55m/s
Snow load: max.1.5kN/m²
Laminates/modules:Framed and unframed
Module layout: In series, 6 pcs modules per unit
Module orientation: Vertical or horizontal
Setting angle: 5°-60°
Surface treatment: Stainless steel & anodised AL
Material: Stainless steel SUS304,Aluminium 6063-T5
Standard: Suit for EU,AU,US standard
Warranty: 10 years durability on materials
Application
